#370763 - 04/04/2018 20:53 Laptop docks (again) - Mac broke them, now what?
tfabris
carpal tunnel

Registered: 20/12/1999
Posts: 31159
Loc: Seattle, WA
Thanks to this new and interesting news:
https://discussions.apple.com/thread/8339158

I no longer have a working docking station solution for dual external monitors. I updated my Mac OS without knowing that it would break my external HDMI monitors.

I have a special need which requires me to have the ability to swap out which laptop I'm using on my dual monitors on my home desk. I swap between my home laptop, my work laptop, and my mac, depending on the situation. When all three devices supported DisplyLink, it was easy, I could just plug them into the dock. Now... not so much.

I can also use a Mac USB-C Digital AV Multiport Adapter successfully, but that gets me only one external HDMI monitor, not two. In fact, I have been successfully doing a hybrid where monitor 1 is driven off the HDMI plug from that thing, and monitor 2 is driven off the DisplayLink dock, for quite a while. But now, the second DisplayLink display just goes black.

I could upgrade to a pair of "Thunderbolt 3" monitors at great expense, and then my mac would work, but then my PCs wouldn't work with those monitors when I needed to do stuff on them. (would they? I don't understand the relationship between USB3 and Thunderbolt 3.) Problem is that all the new displays are super high rez, and honestly, what I really want is a pair of old 1920x1080 displays like I've currently got because the new super high rez displays are way too fine for my aging eyesight.

Also, I have this thing where one of the HDMI plugs going to one of the monitors goes to a HDMI splitter that goes to the TV next to the recording booth, allowing me to see/control the DAW from the booth. That's super useful and I don't want to lose that either.

I could become the operator from The Matrix and have four monitors I suppose, two PC and two mac. Again: expense of the extra monitors and added mounting bracketry.

I wonder if I'd be happy with one super ultra wide screen instead of two regular screens? Those are pricey too, though, and I have no idea if my Windows laptops' HDMI ports would even support it.

Any other ideas of what would work for me?

This sucks because I had a working system that I was happy with, even though it was kinda frankenstein, it worked, and now a software updated fried it all.
_________________________
Tony Fabris

Top
#370764 - 04/04/2018 20:59 Re: Laptop docks (again) - Mac broke them, now what? [Re: tfabris]
tfabris
carpal tunnel

Registered: 20/12/1999
Posts: 31159
Loc: Seattle, WA
Heh, this one says it supports thunderbolt and USB-C and displayLink, but....
https://www.amazon.com/Plugable-Charging-Delivery-Specific-Thunderbolt/dp/B01FKTZLBS
... they just added text to the listing saying "NOT macOS COMPATIBLE (10.13.4 version and later)."

Heh.
_________________________
Tony Fabris

Top
#370765 - 04/04/2018 21:26 Re: Laptop docks (again) - Mac broke them, now what? [Re: tfabris]
tfabris
carpal tunnel

Registered: 20/12/1999
Posts: 31159
Loc: Seattle, WA
Hm. If I remember correctly, these monitors I've got have both DVI and HDMI inputs and I can switch between those inputs on their front panel.

If I got something like this...
Thunderbolt 3 to Dual HDMI Adapter

Then I could theoretically connect the older gear with DVI cables and the mac with the HDMI cables and just switch between the inputs on the monitor front panels.

In theory.

Sad, though, that those dual-HDMI thunderbolt adapters don't also have a USB connection and a power charging pass through. At least I don't see one available. You either get a single HDMI and the USB and power charging pass through, or you get dual HDMI, not both. Does that seem to hold true?
_________________________
Tony Fabris

Top
#370766 - 05/04/2018 00:03 Re: Laptop docks (again) - Mac broke them, now what? [Re: tfabris]
Shonky
pooh-bah

Registered: 12/01/2002
Posts: 1956
Loc: Brisbane, Australia
TB3 uses the USB-C connector and allows extra things like power delivery, Displayport pass through as well as higher total throughput (40Gbps from memory). With a simple USB-C to DisplayPort or HDMI adapter you run your monitor directly off your internal video "card".

The DisplayLink stuff is a self contained video "card" that connects via USB. So in theory you can have many of them connected. I think I've seen a demo with ~16 connected at once.

USB3 is just USB (so no video passthrough or power delivery). So any display connected via a USB3 only port will require DisplayLink or similar adapter.

USB3 can be supplied via a USB-C physical interface so you can't tell by looking at the port.


Edited by Shonky (05/04/2018 00:17)
_________________________
Christian
#40104192 120Gb (no longer in my E36 M3, won't fit the E46 M3)

Top
#370767 - 05/04/2018 00:21 Re: Laptop docks (again) - Mac broke them, now what? [Re: tfabris]
K447
addict

Registered: 29/05/2002
Posts: 674
Loc: Toronto, Ontario, Canada
Originally Posted By: tfabris
Hm. If I remember correctly, these monitors I've got have both DVI and HDMI inputs and I can switch between those inputs on their front panel.

If I got something like this...
Thunderbolt 3 to Dual HDMI Adapter

Then I could theoretically connect the older gear with DVI cables and the mac with the HDMI cables and just switch between the inputs on the monitor front panels.

In theory.

Sad, though, that those dual-HDMI thunderbolt adapters don't also have a USB connection and a power charging pass through. At least I don't see one available. You either get a single HDMI and the USB and power charging pass through, or you get dual HDMI, not both. Does that seem to hold true?
I have two of these
Cable Matters Thunderbolt 3 to Dual 4K or Single 5K DisplayPort Adapter for Mac & Selected Windows
(Not Compatible with USB-C ports without the Thunderbolt Logo)

Each is plugged into a 2016 MacBook Pro 15 inch (one on each side). Total of four 4K screens are connected via these two adapters. I selected this particular adapter specifically for the additional bandwidth and video capacity of Thunderbolt 3 over USB-C adapters.

There are also USB-C docking stations that provide for two video outputs. Typically one output is HDMI right from the dock. The second video would be via a USB-C to HDMI (or to DisplayPort) adapter, daisy chained behind the dock to feed the second display.

Since I am Mac only, I also use a CalDigit TS3 Thunderbolt 3 docking station, recently superseded by the CalDigit TS3 Plus


Edited by K447 (05/04/2018 00:33)

Top
#370768 - 05/04/2018 02:02 Re: Laptop docks (again) - Mac broke them, now what? [Re: tfabris]
tanstaafl.
carpal tunnel

Registered: 08/07/1999
Posts: 5370
Loc: Ajijic, Mexico
Originally Posted By: tfabris
it worked, and now a software updated fried it all.
Can you not just roll back to 10.13.3?

tanstaafl.
_________________________
"There Ain't No Such Thing As A Free Lunch"

Top
#370769 - 05/04/2018 02:53 Re: Laptop docks (again) - Mac broke them, now what? [Re: tfabris]
K447
addict

Registered: 29/05/2002
Posts: 674
Loc: Toronto, Ontario, Canada
Originally Posted By: tfabris
Thanks to this new and interesting news:
https://discussions.apple.com/thread/8339158

I no longer have a working docking station solution for dual external monitors. I updated my Mac OS without knowing that it would break my external HDMI monitors.

I have a special need which requires me to have the ability to swap out which laptop I'm using on my dual monitors on my home desk. I swap between my home laptop, my work laptop, and my mac, depending on the situation. When all three devices supported DisplayLink, it was easy, I could just plug them into the dock. Now... not so much.

... the second DisplayLink display just goes black.

...

I could ... have four monitors I suppose ...

.... I had a working system that I was happy with, even though it was kinda frankenstein, it worked, and now a software updated fried it all.
I used a DisplayLink USB 2.0 docking station for several years with my MacBook Air. While it ‘worked’, every single macOS update brought risk of problems, if not complete unusability. Eventually the problems would get resolved and I could have both external screens working again.

The DisplayLink support forums for Mac had a general sadness, with familiar postings of known problems, and monthslong threads waiting for a software update fix.

When I was finally able to buy the first generation of Mac compatible Thunderbolt 3 docking stations, I was happy to unplug that DisplayLink thing and set it aside.

There is a USB 3.0 DisplayLink chipset which is supposedly better supported (but see above). I have not used one, and have no interest in spending any more time trialing DisplayLink driver software and firmware, often only available as Beta and sometimes ‘released’

I do have four external displays connected to a single computer, but only two during my DisplayLink era.


Edited by K447 (05/04/2018 02:58)

Top
#370770 - 05/04/2018 16:03 Re: Laptop docks (again) - Mac broke them, now what? [Re: K447]
tfabris
carpal tunnel

Registered: 20/12/1999
Posts: 31159
Loc: Seattle, WA
Originally Posted By: K447
There is a USB 3.0 DisplayLink chipset which is supposedly better supported (but see above).

Unfortunately this bug is across all DisplayLink devices, regardless of chipset.


Originally Posted By: tanstaafl.
Can you not just roll back to 10.13.3?

That is something I am thinking about. However I'm not sure if there's an easy procedure for that. My google searches only result in information regarding how to roll back to an older "major" version rather than the small rollback I would want to do.


Originally Posted By: K447
There are also USB-C docking stations that provide for two video outputs. Typically one output is HDMI right from the dock. The second video would be via a USB-C to HDMI (or to DisplayPort) adapter, daisy chained behind the dock to feed the second display.

Since I am Mac only, I also use a CalDigit TS3 Thunderbolt 3 docking station, recently superseded by the CalDigit TS3 Plus

Thanks, I'm definitely going to investigate those docks. I initially discounted them since they only had 1 HDMI output but your hint that I could daisy chain a USB-C-to-HDMI adapter into them (something I already own) means that I could do that too.

This theoretically should allow me to switch back and forth between the PC gear and the Mac gear by tapping the "input" button on my monitor front panels. (PC Gear connected to DVI ports on monitors, Mac gear connected to HDMI ports on monitors.) Anyone see a flaw in that scheme that I might have missed? For example if the docks say that they're "USB-C" docks like those recommended ones, is there a chance that they're using DisplayLink under the hood or something? Or would a USB-C-to-HDMI adapter use DisplayLink under the hood?

Thanks, gang!
_________________________
Tony Fabris

Top
#370771 - 05/04/2018 16:26 Re: Laptop docks (again) - Mac broke them, now what? [Re: tfabris]
tfabris
carpal tunnel

Registered: 20/12/1999
Posts: 31159
Loc: Seattle, WA
The CalDigit TS3 Plus is new enough to be not available on Amazon yet, but it looks real nice. I'll probably grab one once they're more widely available.

In the meantime, I did Amazon same-day-delivery on a less expensive thunderbolt-to-dual-HDMI plug adapter to get me by for now and to see if my scheme will even work.
_________________________
Tony Fabris

Top
#370772 - 05/04/2018 19:32 Re: Laptop docks (again) - Mac broke them, now what? [Re: tfabris]
K447
addict

Registered: 29/05/2002
Posts: 674
Loc: Toronto, Ontario, Canada
Originally Posted By: tfabris
...

... I'm definitely going to investigate those docks. I initially discounted them since they only had 1 HDMI output but your hint that I could daisy chain a USB-C-to-HDMI adapter into them (something I already own) means that I could do that too.

... Anyone see a flaw in that scheme that I might have missed? For example if the docks say that they're "USB-C" docks like those recommended ones, is there a chance that they're using DisplayLink under the hood or something? Or would a USB-C-to-HDMI adapter use DisplayLink under the hood?
...
This is a tricky bit. Thunderbolt 3 has a well defined video channel structure. The actual video processing happens inside the video chip on computer/laptop. Video bitstream flows over Thunderbolt 3, signal converted to HDMI/DisplayPort/DVI and down the cable.

USB-C has several ways to display video, you may have to read the details on each adapter or dock.

DUAL external video output can be quite different from single external video, USB-C may have limitations. I chose Thunderbolt 3 specifically to avoid USB-C limitations.

Top
#370773 - 05/04/2018 20:39 Re: Laptop docks (again) - Mac broke them, now what? [Re: K447]
tfabris
carpal tunnel

Registered: 20/12/1999
Posts: 31159
Loc: Seattle, WA
Thanks for that information. That's useful.

The device I ordered is pretty specific about being a thunderbolt 3 device with two HDMI outputs. It's not the same brand as the CableMatters one that you recommended, but it looks like it's the same class of device. (I ordered a different brand because I could get it faster.)

I'll be more careful if I ever get USB-3 type HDMI adapters to make sure they're not DisplayLink devices if I want to use them with a Mac.
_________________________
Tony Fabris

Top
#370775 - 05/04/2018 22:13 Re: Laptop docks (again) - Mac broke them, now what? [Re: tfabris]
mlord
carpal tunnel

Registered: 29/08/2000
Posts: 13872
Loc: Canada
Originally Posted By: tfabris
I'll be more careful if I ever get USB-3 type HDMI adapters to make sure they're not DisplayLink devices if I want to use them with a Mac.

Or anything other than MS-Win. They're pretty much a single-OS paperweight kind of device. wink

Top
#370778 - 05/04/2018 22:22 Re: Laptop docks (again) - Mac broke them, now what? [Re: mlord]
tfabris
carpal tunnel

Registered: 20/12/1999
Posts: 31159
Loc: Seattle, WA
It's funny because before I got a Mac, I made sure DisplayLink worked with it. I used a friend's Macbook on my displayLink docking station to be sure. It only stopped working last Friday. It's been real good in the meantime.
_________________________
Tony Fabris

Top
#370781 - 06/04/2018 09:33 Re: Laptop docks (again) - Mac broke them, now what? [Re: tfabris]
andy
carpal tunnel

Registered: 10/06/1999
Posts: 5747
Loc: Wivenhoe, Essex, UK
Don't say I didn't warn you wink cry

http://empegbbs.com/ubbthreads.php/topics/355335/Re:_DisplayLink_review#Post355335

Last time DisplayLink was broken on OSX for something like two years before they managed to fix it.
_________________________
Remind me to change my signature to something more interesting someday

Top
#370782 - 06/04/2018 09:40 Re: Laptop docks (again) - Mac broke them, now what? [Re: tfabris]
andy
carpal tunnel

Registered: 10/06/1999
Posts: 5747
Loc: Wivenhoe, Essex, UK
Originally Posted By: tfabris

I wonder if I'd be happy with one super ultra wide screen instead of two regular screens?


That was basically my solution when it happened to me last time DisplayLink got broken by OSX changes. I switched from MacBook screen + 2 * 1920x1080 screens, to MacBook screen and one 27 inch 2560x1440 screen.

Nowadays that is what I prefer, one biggish monitor above my MacBook screen (I'm one of these odd people who use their MacBooks open plugged into a second screen rather than closed with external keyboard and pointing device).

I make extensive use of keyboard shortcuts in BetterSnapTool to actually use my 27 inch monitor as if it was two portrait-ish monitors.
_________________________
Remind me to change my signature to something more interesting someday

Top
#370783 - 06/04/2018 11:37 Re: Laptop docks (again) - Mac broke them, now what? [Re: andy]
K447
addict

Registered: 29/05/2002
Posts: 674
Loc: Toronto, Ontario, Canada
Originally Posted By: andy
Originally Posted By: tfabris

I wonder if I'd be happy with one super ultra wide screen instead of two regular screens?


... to MacBook screen and one 27 inch 2560x1440 screen.

Nowadays that is what I prefer, one biggish monitor above my MacBook screen (I'm one of these odd people who use their MacBooks open plugged into a second screen rather than closed with external keyboard and pointing device).

... keyboard shortcuts in BetterSnapTool ...
I also have my MacBook open in front/below the external displays. I also upgraded to 4K screens a year ago and highly prefer them over the HD (1600x1200) I had before. Font sizes are not a problem as the Mac lets me scale the UI to suit my (not so young anymore) eyes.

That said, I am using 32” 4K screens which is larger than my television was years ago cool

I considered buying super wide displays but found that the vertical resolution was not much better than plain old HD. For my use case curved screens introduced a visual effect that I disliked.

I shall look into the BetterSnap Tool , might be useful.

Top
#370786 - 06/04/2018 17:53 Re: Laptop docks (again) - Mac broke them, now what? [Re: K447]
tfabris
carpal tunnel

Registered: 20/12/1999
Posts: 31159
Loc: Seattle, WA
Originally Posted By: K447
I also have my MacBook open in front/below the external displays. I also upgraded to 4K screens a year ago and highly prefer them over the HD (1600x1200) I had before. Font sizes are not a problem as the Mac lets me scale the UI to suit my (not so young anymore) eyes.

Yes, the Mac is much better about font and icon size scaling than Windows is. Windows is trying hard to get better, but I still run into tons of problems with it. For example, let's say I'm on the Mac and I'm remote desktopping into a Windows box, and I want to increase the scaling on the Windows screen, Windows literally won't let me change the scaling in RDP mode. Other times, I run into problems where the scaling is wrong depending on whether I booted the Windows box while docked to an external screen or whether I booted the laptop on its own screen, and then when I dock, not all the scaling settings change back to where they should be. And then there's a problem with older applications which don't respect the scaling, etc.

So since I still use Windows in the mix for various things, I still prefer a screen that's at about 1920x1080 rez so that when the scaling screws up I can still read things. The 1080p resolution is a perfect sweet spot for my eyesight, balancing the amount of data I can fit on the screen at once with the average size of the text of most programs.

Quote:
I considered buying super wide displays but found that the vertical resolution was not much better than plain old HD.

Which would be a good feature for me.


Quote:
For my use case curved screens introduced a visual effect that I disliked.

Aha, that's a really good point. I could see the curved screen being great for gaming, or for watching Cinerama type movies in ultra wide screen. But for any kind of graphical editing, CAD, desktop publishing, or coding, anything where parallel lines are important, I could see the curve potentially really screwing me up.

And it looks like all the ultra wide screens are curved, so, that's a no go for me.


Originally Posted By: andy
Don't say I didn't warn you wink cry

Fair point!

In the meantime, I got things working well again last night.

Temporarily I connected the Mac to two monitors using one each of these, which I already had on hand:
Anker USB-C to HDMI Adapter
Apple USB-C Digital AV Multiport Adapter

Works, but a little unwieldy. I ordered one of these same-day:
Plugable Thunderbolt 3 Dual HDMI 2.0 Display Adapter
... And that works too.

Interesting side note. I also have a weird frankenstien setup where I pipe one of the HDMI outputs through a DVI splitter box (using DVI-HDMI adapter plugs) so that my main 1080p monitor is also echoed to an old LCD TV parked just outside the recording booth. With this old scheme, it used to work fine, the 1920x1080 output would simply appear duplicated on the TV. The TV would scale down the 1080-line image to its native resolution (720p) and it would be enough for me to control the DAW when I was solo-tracking in the booth, and when I went back to the desk to work with the DAW in detail, it would be the same screen, just sharper because it was at native 1080 resolution instead of scaled down for the TV set.

With the new adapters, that scheme no longer succeeds. Something about either the video adapters, the splitter (I have two different ones and tried both), or the new OS update, prevents it from working the way it used to. Now the Mac will only use the lowest common denominator resolution between the displays going through the DVI splitter, and I can't force it back up to 1080 (even with the "Alt+click on Scaled" trick on the Mac). So my desktop screen was only running at 720p, the TV's resolution, which wasn't livable, I needed my 1080-line sweet spot at my desk.

So for now, I'm using a combination of the Plugable dual-HDMI adapter going to my two desktop 1080 monitors, and also the Apple AV Multiport adapter for power, USB docking, and also its HDMI cable goes straight to that LCD TV outside the booth (no splitter any more). So now it's actually three independent external displays instead of two plus a splitter. And they all run at their native resolutions. So this is actually pretty good.

For the Windows PC side of things, the DisplayLink dock still works great and I have it going into different inputs on the two 1080p monitors. The monitors have DVI and HDMI inputs, and the Mac now goes into the HDMI inputs and the DisplayLink dock goes into the DVI inputs, and so I just switch between the inputs depending on which machines are hooked up at the time.

So I've got it all working now, though I'm waiting on some extra cables to make the connections a bit cleaner. And I still want to get a nice Thunderbolt 3 docking station to bring everything down to a single wire connection to the Mac.
_________________________
Tony Fabris

Top
#370788 - 06/04/2018 21:34 Re: Laptop docks (again) - Mac broke them, now what? [Re: tfabris]
tfabris
carpal tunnel

Registered: 20/12/1999
Posts: 31159
Loc: Seattle, WA
By the way, for posterity:

I'm told that I could simply use the Time Machine backup system to roll back my system to 10.13.3. Since I religiously keep two redundant backups, this should theoretically be easy.

I hadn't realized that Time Machine could roll back the OS, I thought it was just for my documents. I've never actually needed to use its restoration features before.

I don't need to do it now, since I'm improving the video connections to remove my dependence on their support for DisplayLink, but it's worth noting that it would have been an option for me.
_________________________
Tony Fabris

Top
#370790 - 09/04/2018 02:38 Re: Laptop docks (again) - Mac broke them, now what? [Re: tfabris]
tfabris
carpal tunnel

Registered: 20/12/1999
Posts: 31159
Loc: Seattle, WA
Okay, now I have a question about extending Thunderbolt 3 cabling.

I want to be able to extend the "reach" of these two devices currently hanging awkwardly off the MacBook Pro:

1. Apple USB-C Digital AV Multiport Adapter
2. Plugable Thunderbolt 3 HDMI Adapter

They both have very short cords, meaning that they hang off the side of the desk where the Mac is perched and there is stress on the USB ports on the Mac that way. (The other way, with them lying on the desk next to the Mac, means they get in the way on the desktop, there's not enough room for them to be livable that way).

I figured, while I'm in the process of re-doing the video wiring, I'll also get some extension cables to fix that problem. I need about 6 feet of extension to do the thing I need to do.

Well, I ordered a couple of 6ft TUSITA USB-C Extension Cables and they flat out don't work for this purpose. For power supplying through the Digital AV multiport adapter, it's a no-go, the Mac keeps going back and forth between charging and not charging every few seconds, emitting a "BONG!" sound every time it flips. And for the HDMI adapter it just flat out doesn't register a connection at all.

My next thought was "oops, the cheapass cables I bought don't say Thunderbolt on them, so I should get nicer ones instead", and looked for ones which did say Thunderbolt on them. The first ones I found were these DISDM extension cables which say "thunderbolt" but I'm very VERY leery about them because of the following text in a review:
Originally Posted By: Sirin
Not recommended if you need video transfer. I bought this cord to extend the cord of the USB-C Digital AV Multiport Adapter to my MacBook. The cord allows power and USB-A data transfer, but not HDMI. The seller did not respond to my request for assistance.


There is a similar comment in a product review for a similar cable by Dreamvasion, describing the exact same issue that I encountered.

So I'm actually not seeing any extension cables that will work for what I want. There's are multiple different certified 40gbps Thunderbolt cables in my desired length, but they won't plug into the devices I need because they're male-male. I need a female-male because the devices in question don't have a female plug, they have a male dingledangle instead of a hole. I'm afraid if I try a short fem-fem adapter to get the dingledangle to connect to the certified 40gbps cable, that I'll simply encounter the same problem after having already shelled out the extra scratch for the certified cables.

There's this Apple Insider article which seems to confirm my fears. They recommend the same groups of certified 40Gbps cables that I found above, but don't have any suggestions of extenders to hook to the dingledangles.

Anyone have any advice in this area?
_________________________
Tony Fabris

Top
#370791 - 09/04/2018 04:00 Re: Laptop docks (again) - Mac broke them, now what? [Re: tfabris]
K447
addict

Registered: 29/05/2002
Posts: 674
Loc: Toronto, Ontario, Canada
I think you have run into a reason why the proper docking stations havie a female socket for the Thunderbolt 3 (or USB-C) cable coming from the laptop. An adapter with a pigtail lead is essentially stuck with that cable length. A docking station allows you to buy the Thunderbolt 3 cable length and type (active or passive) necessary to get the required bandwidth for your application).

Similar story for USB-C where you need longer cables.
Notwithstanding the whole power delivery aspect.

I don’t know if there is even such a thing as an ‘extension cable’ for either Thunderbolt 3 or USB-C pigtail adapters that fits within the specifications for those standards.

My own approach was to accept that the docking station and the dual DisplayPort adapters were all going to be present on the desk, tethered on fairly short cables and sort of tucked behind the laptop.

The linked article was quite well done.

Top
#370792 - 09/04/2018 06:07 Re: Laptop docks (again) - Mac broke them, now what? [Re: K447]
tfabris
carpal tunnel

Registered: 20/12/1999
Posts: 31159
Loc: Seattle, WA
Cool, thanks.

OK, well since my long term plan is to get one of those nice docking stations, I'll go with that, assuming I can find a cable that'll let me connect to the dock at 6 feet length. I might get away with 3 feet with some finagling.
_________________________
Tony Fabris

Top
#370793 - 09/04/2018 06:15 Re: Laptop docks (again) - Mac broke them, now what? [Re: tfabris]
tfabris
carpal tunnel

Registered: 20/12/1999
Posts: 31159
Loc: Seattle, WA
Now, another interesting question that digs deep into Mac architecture.

I'm able to use both of these adapters on the Mac at the same time:

1. Apple USB-C Digital AV Multiport Adapter
2. Plugable Thunderbolt 3 Dual-HDMI Adapter

When they are working, I get a total of four available independent screens:
- The Mac laptop screen.
- The dual HDMI outputs going to the two 1080p monitors from the Plugable Dual-HDMI adapter.
- The single HDMI output from the Apple USB-C adapter, going to my 720p LCD television near the recording booth.

BUT.... there seems to be a "catch".

If I plug both those adapters into the two ports on the SAME side of the Mac, for example, plugging them both into the two ports the right side of the Mac, then one of the monitors is always blank. Either the TV screen doesn't show up as an available device, or, the right-hand of the two 1080p monitors doesn't show up as an available device. (Depends on which adapter was plugged in first).

If I plug both those adapters into OPPOSITE sides of the Mac (one right side and one left side), then all four monitors work.

Why?

This puts a damper on my idea of having just a couple of cables dangling off the left side of my desk, and no interference cabling coming out the right side of the Mac into my desktop clutter workspace.
_________________________
Tony Fabris

Top
#370794 - 09/04/2018 06:20 Re: Laptop docks (again) - Mac broke them, now what? [Re: K447]
tfabris
carpal tunnel

Registered: 20/12/1999
Posts: 31159
Loc: Seattle, WA
Originally Posted By: K447
My own approach was to accept that the docking station and the dual DisplayPort adapters were all going to be present on the desk, tethered on fairly short cables and sort of tucked behind the laptop.


Clarifying quesion: You are doing two cables? One to the docking station and one to the dual DisplayPort adapter?

If so, then question: Is there a reason you're not cutting it down to a single cable by daisy chaining the dual DisplayPort adapter into one of the ports on the docking station? Does that fail to work correctly for some reason?
_________________________
Tony Fabris

Top
#370795 - 09/04/2018 08:24 Re: Laptop docks (again) - Mac broke them, now what? [Re: tfabris]
andy
carpal tunnel

Registered: 10/06/1999
Posts: 5747
Loc: Wivenhoe, Essex, UK
Is this one of the recent MacBook Pro 13 inch models ?

Some of them have a different Thunderbolt setup on the two sides of the machine, something to do with not enough PCI express buses.
_________________________
Remind me to change my signature to something more interesting someday

Top
#370796 - 09/04/2018 08:28 Re: Laptop docks (again) - Mac broke them, now what? [Re: andy]
andy
carpal tunnel

Registered: 10/06/1999
Posts: 5747
Loc: Wivenhoe, Essex, UK
And if it isn’t, PCI express lanes could still be the issue. I expect the have to route a bunch of them to the ports on one side and a bunch of them to the ports on the other side. So if you stick to using just one side you are restricting yourself to using only part of the machines available IO.

Yet another reason why dedicated ports was so much more simple than USB-C/Thunderbolt 3 frown


Edited by andy (09/04/2018 08:29)
_________________________
Remind me to change my signature to something more interesting someday

Top
#370797 - 09/04/2018 12:35 Re: Laptop docks (again) - Mac broke them, now what? [Re: tfabris]
K447
addict

Registered: 29/05/2002
Posts: 674
Loc: Toronto, Ontario, Canada
Originally Posted By: tfabris
Now, another interesting question that digs deep into Mac architecture.

I'm able to use both of these adapters on the Mac at the same time:

1. Apple USB-C Digital AV Multiport Adapter
2. Plugable Thunderbolt 3 Dual-HDMI Adapter

When they are working, I get a total of four available independent screens:
- The Mac laptop screen.
- The dual HDMI outputs going to the two 1080p monitors from the Plugable Dual-HDMI adapter.
- The single HDMI output from the Apple USB-C adapter, going to my 720p LCD television near the recording booth.

BUT.... there seems to be a "catch".

If I plug both those adapters into the two ports on the SAME side of the Mac, for example, plugging them both into the two ports the right side of the Mac, then one of the monitors is always blank. Either the TV screen doesn't show up as an available device, or, the right-hand of the two 1080p monitors doesn't show up as an available device. (Depends on which adapter was plugged in first).

If I plug both those adapters into OPPOSITE sides of the Mac (one right side and one left side), then all four monitors work.

Why?

This puts a damper on my idea of having just a couple of cables dangling off the left side of my desk, and no interference cabling coming out the right side of the Mac into my desktop clutter workspace.
The maximum number of displays that a single Thunderbolt 3 chip can feed is two, on the Mac.

The larger MacBook Pro with Thunderbolt 3 have two chips, one feeds the left side, one feeds the right side. So I have two monitors connected to the left side via a single adapter and everything else is connected to the right side.

Right side has a single Thunderbolt 3 cable to docking station, then daisy chain to the other two displays.

Hmmm, maybe I should swap the docking station to the left side port ... I seem to recall the left side ports have more bandwidth? Need to check that!

Top
#370798 - 09/04/2018 14:48 Re: Laptop docks (again) - Mac broke them, now what? [Re: tfabris]
tanstaafl.
carpal tunnel

Registered: 08/07/1999
Posts: 5370
Loc: Ajijic, Mexico
Originally Posted By: tfabris
They both have very short cords, meaning that they hang off the side of the desk where the Mac is perched and there is stress on the USB ports on the Mac that way.
I solve that problem with sticky-back Velcro.

tanstaafl.
_________________________
"There Ain't No Such Thing As A Free Lunch"

Top
#370799 - 09/04/2018 15:29 Re: Laptop docks (again) - Mac broke them, now what? [Re: K447]
tfabris
carpal tunnel

Registered: 20/12/1999
Posts: 31159
Loc: Seattle, WA
Originally Posted By: K447
The larger MacBook Pro with Thunderbolt 3 have two chips, one feeds the left side, one feeds the right side.


Aha, that explains it. Yeah, I've got a 15" Macbook Pro.

Blast, though, it means that, no matter what, I'm using two cables, and they have to be inconveniently placed on two sides of the Mac instead of one.

Maybe a docking station with an external GPU is in my future, if such a thing is being made some day.

Quote:
I seem to recall the left side ports have more bandwidth? Need to check that!


According to this, that limitation is on the 13 but not the 15 if I'm reading it right:
https://www.macrumors.com/2016/10/28/macbook-pro-tb3-reduced-pci-express-bandwidth/
_________________________
Tony Fabris

Top
#370801 - 09/04/2018 18:49 Re: Laptop docks (again) - Mac broke them, now what? [Re: tfabris]
tfabris
carpal tunnel

Registered: 20/12/1999
Posts: 31159
Loc: Seattle, WA
Originally Posted By: tfabris
If so, then question: Is there a reason you're not cutting it down to a single cable by daisy chaining the dual DisplayPort adapter into one of the ports on the docking station? Does that fail to work correctly for some reason?


Answering my own question:

Even with that CalDigit TS3 plus, which is probably the most powerful available Mac docking station out there, you still can't do this. I talked to CalDigit support and their dock can support a maximum of two external displays: One via its own video port, and one via its thunderbolt port. Attempting to daisy chain additional video adapters into its Thunderbolt port will not gain me any extra displays.

I'd be happy with two displays total if only my splitter trick for the recording booth monitor had kept working. Alas, this looks like it's not the case.
_________________________
Tony Fabris

Top
#370803 - 09/04/2018 22:04 Re: Laptop docks (again) - Mac broke them, now what? [Re: tanstaafl.]
Roger
carpal tunnel

Registered: 18/01/2000
Posts: 5572
Loc: London, UK
Originally Posted By: tanstaafl.
Originally Posted By: tfabris
they hang off the side of the desk
I solve that problem with sticky-back Velcro.


I've got a few of these. They're grippy, they're surprisingly weighty, and they're pretty good at keeping your cables on your desk.

I also have some sticky-back cable grips. A quick search found me these, which aren't the same as the ones as I've got, but it looks like they'll do the job.

But, then again, I've also got holes cut into my desk and a few Desk Grommets strategically located.

That's when I haven't simply cable-tied (or velcro-tied) the cables to my monitor mount arms.

Edit: while looking for more examples of cable-tidying porn, I found these cable hooks. Tempting.

Edit Edit: They don't appear to be easy to find, but it occurs that a set of cheap, but not too cheap, storage hooks would be suitable. Something like this, but maybe with less overkill.
_________________________
-- roger

Top
#370805 - 09/04/2018 22:27 Re: Laptop docks (again) - Mac broke them, now what? [Re: Roger]
tfabris
carpal tunnel

Registered: 20/12/1999
Posts: 31159
Loc: Seattle, WA
Originally Posted By: Roger
I've got a few of these. They're grippy, they're surprisingly weighty, and they're pretty good at keeping your cables on your desk.

Those look pretty cool. I'll look into some of those for general usage.


Still doesn't solve what the heck to do with the Apple AV Multiport Adapter, whose dingledangle is so supidly short as to make any positioning other than "hang off the side" impossible. Not enough length on that cord to do the things I would need to make cord holders or velcro sticky work. I could really use some kind of extender for that thing which works.
_________________________
Tony Fabris

Top
#370806 - 09/04/2018 23:41 Re: Laptop docks (again) - Mac broke them, now what? [Re: tfabris]
K447
addict

Registered: 29/05/2002
Posts: 674
Loc: Toronto, Ontario, Canada
Originally Posted By: tfabris
... what the heck to do with the Apple AV Multiport Adapter, whose dingledangle is so supidly short as to make any positioning other than "hang off the side" impossible. ...

Originally Posted By: tfabris
...
The device I ordered is pretty specific about being a thunderbolt 3 device with two HDMI outputs. It's not the same brand as the CableMatters one that you recommended, but it looks like it's the same class of device. (I ordered a different brand because I could get it faster.)
...
Why not buy two of these devices?

One on each side of the MacBook Pro 15”

Is there something about the Apple adapter that makes it indispensable?

Top
#370807 - 10/04/2018 15:41 Re: Laptop docks (again) - Mac broke them, now what? [Re: K447]
tfabris
carpal tunnel

Registered: 20/12/1999
Posts: 31159
Loc: Seattle, WA
Power.
_________________________
Tony Fabris

Top
#370808 - 10/04/2018 17:12 Re: Laptop docks (again) - Mac broke them, now what? [Re: tfabris]
tfabris
carpal tunnel

Registered: 20/12/1999
Posts: 31159
Loc: Seattle, WA
More specifically, my goals are:
- Fewest possible number of cables to dock every time.
- Need to plug in charging power.
- Need to plug into a USB hub.
- Need to plug into at least two external HDMI displays.
- Hopefully also plug into a third external HDMI display.

The Apple AV Multiport adapter took care of all of the above with a single cable, until they broke DisplyayLink and the USB couldn't daisychain into a DisplayLink dock any more. I have had (and still have) the multiport adapter dangling off the side of the desk for a long time, but I never liked how it put stress on the port on the side of the computer, and I'm worried that if I keep doing that it'll eventually break.

My final solution will be a full docking station (I put in an order for the CalDigit TS3 with a 6-foot certifed cable, but the product doesn't actually exist for me yet), plus the dual-HDMI thingy plugged into the opposite side of the laptop.

I don't like the two-cable solution, and I particularly don't like the two-sides-of-the-laptop thing, but it appears that I don't have a choice at the moment.
_________________________
Tony Fabris

Top
#371114 - 13/07/2018 23:23 Re: Laptop docks (again) - Mac broke them, now what? [Re: tfabris]
JBjorgen
carpal tunnel

Registered: 19/01/2002
Posts: 3493
Loc: Guadalajara, MX
I'll just leave this here: Blackmagic eGPU.
_________________________
~ John

Top
#371115 - 13/07/2018 23:33 Re: Laptop docks (again) - Mac broke them, now what? [Re: tfabris]
JBjorgen
carpal tunnel

Registered: 19/01/2002
Posts: 3493
Loc: Guadalajara, MX
I'm assuming you could plug the dual-HDMI thingy into the second Thunderbolt port, use the built-in HDMI for the third port, and use the built-in USB hub, and thus have all of your gear on a single thunderbolt plug with even greater performance. Convenience certainly comes at a price though.
_________________________
~ John

Top
#371120 - 14/07/2018 19:22 Re: Laptop docks (again) - Mac broke them, now what? [Re: JBjorgen]
tfabris
carpal tunnel

Registered: 20/12/1999
Posts: 31159
Loc: Seattle, WA
Ah, thanks for reminding me that I needed to follow up on this thread with my solution.

The external GPU looks really nice. I find it interesting that it does not have dual monitor outputs. It's got a USB hub and some Thunderbolt pass throughs, though, so you could still daisy chain stuff downstream from it, but it's not a dock replacement. No ethernet or audio connectors, for example.

My final working solution is this:

I got a Caldigit TS3 Plus and I am very happy with it. They were sold out at first, so I got on the preorder list and it arrived a couple weeks later. The TS3 Plus is still not the perfect solution because I still have to deal with multiple peripheral dongle adapters to get all my stuff working. What this world really needs is a dock with dual monitor outputs along with all the other stuff that's in the TS3 Plus.

In the meantime, here is my current desk setup which is working well:

Windows laptop:
- Single-cable dock: USB 3 connection to my existing DisplayLink dock.
- DVI outputs from DisplayLink dock go into the DVI inputs on my existing dual monitors.

Mac laptop:
- Single-cable dock: Certified high speed thunderbolt cable to Caldigit TS3 Plus dock (you choose cable length when you order the dock).
- Video output port on the TS3+ is unused.
- Thunderbolt port on the TS3+ has a dual-HDMI thunderbolt adapter plugged into it.
- HDMI outputs from the dual-HDMI adapter go to the HDMI inputs on my existing dual monitors.
- As long as I don't try to use the video output on the TS3+, nor try to plug another video adapter into that same side of the Mac, then both monitors always work. I cannot drive a third monitor from that side of the Mac, regardless of docks or daisy chaining, due to the aforementioned "two monitors per thunderbolt chip max" limitation on macs.

Now I can switch displays between the Windows and Mac computers just by tapping the "input" button on the front of each monitor.

USB stuff:
- Peripherals which I only use with the Windows computer are plugged into the USB ports on the Displaylink dock.
- Peripherals which I only use with the Mac computer are plugged into the USB ports on the TS3+ dock.
- I have a USB3 hub which is the "common" hub for both systems, hosting the peripherals which are used by both computers.
- There are USB extension cables (with female "A" ends) coming from each dock, as well as the upstream cable from the USB3 hub. I have placed the ends of these three cables where I can reach them. When I switch between using the Mac and the Windows computers, I swap which of the docks gets connected to the USB3 hub, by swapping the extension cables.

The extra monitor for the recording booth:
- When I need to go into the booth, I have a thunderbolt single-HDMI adapter that I can plug into the other side of the Mac. As long as I don't plug it into the same side of the Mac as the TS3+ dock, then all monitors work.
- This is the one thing that breaks my "single-cable dock" goal, but since I don't need the booth monitor very often, I think that's OK.

In the end, I think this is a lot of trouble to go to for docking multiple computers. Everything will be USBC soon enough and I'll have to redo it all I suppose.

Long-term, I expect we'll get the ability to use any/all external displays wirelessly like they do in The Expanse. If you haven't seen the series, all handheld computers can cast to any nearby video or holographic display just by gesturing at the external display with the handheld device. It's quite elegant. The concept of "flinging" to an external display is something that predates the series, but I think they handle it well.

_________________________
Tony Fabris

Top
#371121 - 14/07/2018 19:30 Re: Laptop docks (again) - Mac broke them, now what? [Re: JBjorgen]
tfabris
carpal tunnel

Registered: 20/12/1999
Posts: 31159
Loc: Seattle, WA
Originally Posted By: JBjorgen
I'm assuming you could plug the dual-HDMI thingy into the second Thunderbolt port, use the built-in HDMI for the third port, and use the built-in USB hub,


To clarify, that won't work because of the Mac's "Two monitors per thunderbolt chip" limit. I have the same limit on the TS3+ dock.
_________________________
Tony Fabris

Top
#371122 - Yesterday at 01:09 Re: Laptop docks (again) - Mac broke them, now what? [Re: tfabris]
JBjorgen
carpal tunnel

Registered: 19/01/2002
Posts: 3493
Loc: Guadalajara, MX
Originally Posted By: tfabris

To clarify, that won't work because of the Mac's "Two monitors per thunderbolt chip" limit. I have the same limit on the TS3+ dock.


Out of curiosity, is this a specific thunderbolt chip limit, a GPU limit, or a limitation of the thunderbolt 3 spec?
_________________________
~ John

Top
#371123 - Yesterday at 01:31 Re: Laptop docks (again) - Mac broke them, now what? [Re: tfabris]
mlord
carpal tunnel

Registered: 29/08/2000
Posts: 13872
Loc: Canada
Thunderbolt is just a different PCIe interface (for purposes of this discussion), so I would guess that the limit must be either a software thing or a hardware limit of the specific GPU devices involved.


Other PCIe GPU devices can handle 3 monitors (a connector space limit).

Top
#371124 - Yesterday at 02:00 Re: Laptop docks (again) - Mac broke them, now what? [Re: tfabris]
JBjorgen
carpal tunnel

Registered: 19/01/2002
Posts: 3493
Loc: Guadalajara, MX
That's why I was wondering. Since the Blackmagic eGPU is a separate GPU, perhaps 3 monitors concurrently will work. It's so new, I haven't actually been able to find anyone who has tried it yet.

Of course if it is a software limit, there's no sense in trying to wait for it to change. Apple will do what they please when they want to do it. It will be best for you and you WILL like it. smile
_________________________
~ John

Top
Page 1 of 2 1 2 >
